Reflex type level gauge Wise L100, L110, L120

  • Giá bán: Liên hệ nhận báo giá
  • Danh mục: Đồng hồ áp suất Wise
  • Thương hiệu: Wise
  • Bảo hành: Có
  • Xuất xứ: Chính hãng
  • Hỗ trợ giao hàng: Có

    Thông tin sản phẩm

    Reflex liquid level gauge has a sturdily constructed body, with the glass and cover securely held by U-bolts to maintain a hermetic seal (see figure below). This type of level gauge features several parallel grooves cut into the glass surface that is in contact with the liquid. The resulting prismatic diffraction gases to appear white by reflection : liquids black by absorption thus the level of even transparent liquids can be clearly observed. Low-medium and high-pressure type may be used according to application conditions and units may be manufactured using carbon steel, stainless steel or a wide variety of other materials for parts in contact with the liquid. Type L100 reflex gauges have a number of further advantages including light weight, availability of long visible lengths and low price.

    Material Carbon steel
    Stainless steel
    A182-F11, 22, 5, 9, 91 and Monel
    Alloy-20, etc.
    Visible length 90 ~ 3,510 mm
    Max. No. of section 10 sections
    Vessel connection ¾" or 1" flanged ANSI 150 ~ 2,500 Lb
    Option ● Scale plate
    - Unit : Centimeter, Meter
    ● Vent
    - Needle valve
    Gate valve
    Globe valve
    - Nipple and cap
    ● Drain
    - Needle valve
    - Gate valve
    - Globe valve
    - Nipple and cap
    ● Bracket
    - Longer than 3,000 mm of C to C

    Hình ảnh sản phẩm

    product image
