Động cơ điều khiển van Sunyeh OM-2

    Thông tin sản phẩm Động cơ điều khiển van Sunyeh OM-2

    product image

    Động cơ điều khiển van Sunyeh OM-2 Motorized Valve Actuator Sunyeh OM-2. (Sun Yeh OM-2). Bộ chuyển động điện Electric Actuator OM-2

    • Power:40W
    • Max Torque:120 N.m/1063 lb.in
    • Speed:8 Sec/90°
    • Weight:5.5 kg/12.13 lb
    • Manual Override:N/A
    • Mounting Flange(ISO 5211:F07

    Enclosure:

    • IP65 : Water-proof and dust-proof enclosure.
    • Material : Plastic cover and dry powder coating aluminum alloy base.

    Motor :

    • Standard extended duty cycle induction motor. F (Standard) or H (Optional) insulation class for all models.
    • Built-in thermal protection prevents motor burning out.
    • AC motor:125±5℃/257±9℉
    • DC motor:90±5℃/194±9℉

    Duty Cycle :

    • BM-2:30%duty cycle (Standard Model)

    Working Conditions :

    • Ambient temperature:-30℃ ~ +65℃ / -22℉ ~ +149℉
    • The humidity:30% ~ 95%

    Position Indicator :

    • All models have continuous mechanism position indicator on the top of actuator cover.

    Gear Train :

    • Gear trains have been already lubricated sufficiently with anti-high temperature lubricant at the factory.

    Conduit entrance:

    • Standard : 1/2" PS
    • Optional : 3/4" PF, 1/2" NPT, M20


    Various voltage:

    • AC/DC 12V
    • AC/DC 24V
    • AC 110/220V,1-Phase


    Enclosure

    • Nylon coating
    • E.D. coating
    • Epoxy coating


    Motor insulation class

    • Standard: F class
    • Optional: H class

    Working angle:

    • Standard:0~90°
    • Optional:91~270°
